New Holland: FIMA 2016 & revolution in high power

Since 1895, New Holland is committed to providing solutions that improve efficiency and agricultural productivity through the use of accessible technology. We know the requirements of agricultural machines vary among people looking for a machine to meet their daily tasks; for this and with the experience of over 120 years manufacturing and being a reference in the agricultural sector worldwide, New Holland is presented in FIMA 2016 with a wide range of products and technical innovations.

The new series T7 Heavy Duty cover the range between the nominal power of 270 hp and 315 hp maximum power. Designed to work with the most demanding implements and in the most adverse conditions. FPT engines equipped with HI-eSCR system, 6-cylinder 6.75-liter, common rail injection system high pressure and variable geometry turbo electronic drive (eVGT), delivering maximum power at 1800 rpm.

Delivers maximum torque at 1200 rpm remain constant up to 1800 rpm. Auto Command transmission with 4 mechanical ranges for greater power transfer. Speed ​​of 50km / h ECO 1600 rpm. Front axle suspension Terraglide ™. Terralock ™ system (lock aut. Dif. / DT aut.). Turning radius of 5.7 meters. Lighting 20 LED lights.

The active stop system ensures greater safety on slopes and reduces the need for service brakes. reinforced rear axle wheels can equip 2.15 m in diameter. powerful hydraulic system that develops up to 220 l / min for attachments in high demand. rear linkage with 11,058 kg lift capacity and front linkage with 5,821 kg lift capacity. System monitoring tire pressure built into the monitor IntelliView ™ IV. Class III Isobus innovative system for controlling the tractor by the implement. dynamic control of transport, which makes up the balance by increasing the comfort and safety. SuperSteerTM ABS system that manages each wheel antilock braking power increases, controlling the direction at all times. 630 liters capacity fuel tank and 96-liter AdBlue tank.

T5 Tier IVB

Revolution and redesigning a versatile tractor by definition which will optionally have a suspended front axle. F5G engine meets emission regulations Tier IVB with ECOblueTM technology without particulate filter (DPF). With a fuel saving of 3% compared to Tier IVA; Maximum constant power between 1900-2300 rpm. PowerShift transmission with automatic shift, creeper, march ECO and Parking. Rotatably and unbeatable maneuverability in its category. Wide range of configurations for dual pump hydraulic system. Pala integrated factory assembled. VisionViewTM cab suspension, tire and approved passenger seat. Willingness to Isobus, virtual monitor and GPS.

T6 Tier IVB

With a choice of 6 models from 115 hp rated power up to 158 hp maximum power. Motor Tier IVB ECOBlue ™ HI-eSCR. 16×16 Electro Command ™ transmission, 17×16 Electro Command ™, 32×32 Electro Command with Creeper or Auto Command. hydraulics 127 + 47 liters / min. 3 or 4 rear remotes with 2 or 3 mechanical or electro ventral valves. Lift capacity rear linkage with 90mm cylinders 5254 kg. HorizonTM cabin with a sound level of 69 dBA and Comfort Ride ™ suspension. Class 3 or 4 axes wheelbase 2642mm in standard shaft, 2684mm in axle Terraglide ™ suspension and 2788mm in SuperSteer axle. Four levels of equipment to better suit the needs. New LED lighting 8, 12 or 16 lights. Autoguiding integrated IntelliSteer ™. Isobus Class II. Factory setting for loader. Blue Power Edition model T6.175 Auto Command.

T7 Tier IVB

Series ranging from 140 hp rated power with exclusive model T7.175 to 270 hp maximum power model T7.270. With its 180 hp nominal power and a maximum power of 225 hp with engine power management, the T7.225 is the ideal choice for applications to the PTO and transport. It is available with 710 / 70R38 tires. Motor Tier IVB with HI-eSCR ECOBlue ™ technology that offers more power, torque, torque rise and power management, while maintaining an exceptional responsiveness.

Transmission 18 × 6 of 40 km / h (28×12 with creeper) or 19 × 6 (29×12 with creeper); the latter can offer speeds of 40 km / h at a reduced engine speed for greater savings or a transport speed of 50 km / h. Auto Command transmission benefiting from four points to 100% mechanical transmission that provide maximum efficiency. Low profile ceiling includes more working lights to illuminate a 360 ° area of ​​work and improve productivity by working at night. ISOBUS III incorporate technology. touchscreen color monitor IntelliView ™ IV large. 3 different levels of technology and finishes seats: Auto Comfort ™, Dynamic Comfort ™ or Comfort. Horizon ™ cab with front one-piece.

Compact range

With the firm commitment to provide products that meet the specific needs of all customers, New Holland will present a selection of machines derived from the field of construction chosen for its potential to carry out tasks of agriculture. The product range goes from Skid presented, ideal for small, a Mini with high performance, through the Standard backhoe loaders and spaces. The versatility of these machines coupled with the large amount of implemnetos engageable make this compact range the ideal partner in materials handling tasks. The main agricultural brands assembled FPT Our Motor! Quality, reliability and guarantee of success.

Technical innovations

• Concave sections
• ECOBlue ™ HI-eSCR
• Triple-cleaning shoe CleanTM: New Technology Award 2016 Fima
• Air filtration system cabin Blue Cab 4: New Technology Award 2016 Fima
• System monitoring tire pressure
• System headland sequence HTS II

Source: New Holland
